| 1 |
Medium |
Cement/flour/dust or other bulk particles |
| 2 |
Overall demension |
11300*2500*4000mm(approx) |
| 3 |
Curb weight |
8500kg(approx) |
| 4 |
The height of fifth wheel |
1350mm |
| 5 |
Axle |
13T HCSV Brand with ABS and automatic slack adjusters & 3 units |
| 6 |
Tire |
12R22.5 & 12 units,Triangle Brand |
| 7 |
Rim |
9.00 & 12 units, high strength iron |
| 8 |
King pin |
50#(2″) or 90# (3.5″) standard bolted type |
| 9 |
Landing gear |
Capacity & 28T, JOST Brand |
| 10 |
Suspension |
Leaf spring,16mm*90mm*10pcs |
| Tank body specification |
| 11 |
Tank shape |
V-shape |
| 12 |
Tank capacity |
45CBM |
| 13 |
Tank meterial |
Q235B |
| 14 |
Tank designed
thickness |
End cover: 5 mm |
| Tank body: 4 mm |
| Main parts specification |
| 15 |
Beam |
Heavy duty and extra durability designed T-type beam,opting for high tensile steel Q345,welded by automatic submerged-Arc processes |
| 16 |
Manhole cover |
2 units |
| 17 |
Safety valve |
2 units |
| 18 |
Discharging hose |
1 unit |
| 19 |
Ladder |
1 unit, on the rear |
| 20 |
Pressure gauge |
1 unit |
| 21 |
Spare tire Carrier |
1 unit |
| 22 |
Tool box |
1 unit,as big as we can |
| 23 |
Mud guard plate |
Integrated design plate |
| 24 |
Air compressor |
1 unit,BOHAO Brand, 12CBM power |
| 25 |
Diesel engine |
1 unit,Weichai Brand, 4102 Model |
| 26 |
Optional |
1 unit of water tank, on the rear |
| 27 |
Fire extinguisher |
2 sets of 8KG fire extinguisher and boxes |
| 28 |
Reverse buzzer |
1 unit |
| 29 |
Electric system |
24V, 7-pin socket |
| 30 |
Lights |
LED lights with protection |
| 31 |
Painting |
Painting as customer’s requirements |
| 32 |
Delivery |
Spray wax before departure and tarpaulin for protection |
| 33 |
Others |
All of other necessary accessories |
