| 1 |
Medium |
Petrol/diesel and other fuel oil |
| 2 |
Overall demension |
12000*2500*3700mm(approx) |
| 3 |
Curb weight |
7500kg(approx) |
| 4 |
The height of fifth wheel |
1350mm |
| 5 |
Axle |
13T HCSV Brand with ABS and automatic slack adjusters & 3 units |
| 6 |
Tire |
12R22.5 & 12 units,Triangle Brand |
| 7 |
Rim |
9.00 & 12 units, high strength iron |
| 8 |
King pin |
50#(2″) or 90# (3.5″) standard bolted type |
| 9 |
Landing gear |
Capacity & 28T, Jost Brand |
| 10 |
Suspension |
Leaf spring,16mm*90mm*10pcs |
| Tank body specification |
| 11 |
Tank shape |
Square round and goose neck design |
| 12 |
Tank capacity |
45,000 liters (valid volume) + 5%(ullage) |
| 13 |
Tank meterial |
AL5182 |
| 14 |
Tank designed thickness |
End cover: 7 mm |
| Tank body: 5.5 mm |
| Baffle: 5.5 mm |
| Main parts specification |
| 15 |
Beam |
Heavy duty and extra durability designed T-type beam,opting for high tensile steel Q345,welded by automatic submerged-Arc processes |
| 16 |
Compartment |
3 units,15,000L+15,000L+15,000 for each compartment |
| 17 |
Manhole cover |
Aluminum & 3 units,Jialong Brand |
| 18 |
Bottom valve |
4″ aluminum & 3 units,Jialong Brand |
| 19 |
Discharging valve |
4″ API aluminum & 3 units,Jialong Brand |
| Discharging hose box: 6 meters & 2 units |
| 20 |
Discharging hose |
5.7 meters & 2 units |
| 21 |
Handrail |
2 units on the top |
| 22 |
Walkway platform |
Aluminum, On the top with anti-slip punched design |
| 23 |
Ladder |
1 unit, on the rear or front |
| 24 |
Breath valve |
Aluminum & 3 units |
| 25 |
Spare tire Carrier |
2 units |
| 26 |
Mud guard plate |
Integrated design plate |
| 27 |
Reverse buzzer |
1 unit |
| 28 |
Electric system |
24V, 7-pin socket |
| 29 |
Lights |
LED lights with protection |
| 30 |
Painting |
Aluminum original color without painting or painting as customer’s requirements |
| 31 |
Delivery |
Spray wax before departure and tarpaulin for protection |
| Other equipment |
| 1. |
Single tool box, aluminum, largest as possible as we can |
| 2. |
Single valve box, aluminum, largest as possible as we can |
| 3. |
Single side loading and unloading on left |
| 4. |
2 sets of 8KG fire extinguisher and boxes |
| 5. |
1set of anti-static grounding tape |
| 6. |
All of other necessary tools |
